How to create a recovery partition windows 10​?

A recovery partition in Windows 10 is a crucial component that allows you to restore your system to a previous state in case of errors, crashes, or other issues. It contains important system recovery files and tools. Creating a recovery partition can provide you with a safety net and save you a lot of time and effort in the event of system problems.

Method 1: Using Windows 10 Built-in Tools

Check Available Disk Space

Before creating a recovery partition, it’s essential to check the available disk space on your hard drive. You need to have enough unallocated space to create the partition. You can use the Disk Management tool to check the disk space. Right-click on the Start menu and select “Disk Management”.

Open the Command Prompt as Administrator

Press the Windows key + X and select “Command Prompt (Admin)” from the menu. This will open the Command Prompt with administrative privileges, which are required to perform partition operations.

Create the Recovery Partition

In the Command Prompt, type the following commands one by one:

diskpart – This command launches the DiskPart utility, which is used for disk and partition management.

list disk – This shows a list of all the disks connected to your computer. Identify the disk on which you want to create the recovery partition.

select disk [disk number] – Replace [disk number] with the actual number of the disk you want to work on. For example, if you want to use Disk 0. you would type select disk 0.

create partition primary size=[size in MB] – Replace [size in MB] with the desired size of the recovery partition. A typical size for a recovery partition is around 500 MB to 1000 MB. For example, if you want to create a 500 MB partition, you would type create partition primary size=500.

format fs=ntfs label=”Recovery” – This command formats the newly created partition with the NTFS file system and labels it “Recovery”. You can change the label to something more descriptive if you like.

Assign a Drive Letter (Optional)

If you want to access the recovery partition easily, you can assign a drive letter to it. In the DiskPart utility, type assign letter=[drive letter]. For example, if you want to assign the letter “R” to the recovery partition, you would type assign letter=R.

Copy System Recovery Files

After creating and formatting the recovery partition, you need to copy the system recovery files to it. You can use the robocopy command to copy the files from the original system recovery source (usually located in the Windows installation media or a backup) to the new recovery partition. The command would look something like this: robocopy [source path] [recovery partition drive letter]:\ /e. Replace [source path] with the actual path to the system recovery files and [recovery partition drive letter] with the drive letter you assigned to the recovery partition.

Method 2: Using Third-Party Partition Management Software

Choose a Reliable Third-Party Software

There are several third-party partition management software available, such as ,Panda Assistant and choose the one that suits your needs and has good user reviews.

Download and Install the Software

Visit the official website of the selected software and download the appropriate version for your Windows 10 system. Follow the installation wizard to install the software on your computer.

Launch the Software

After installation, launch the partition management software. You will usually see a graphical interface that displays information about your disks and partitions.

Create the Recovery Partition

In the software interface, locate the disk on which you want to create the recovery partition. Right-click on the unallocated space on the disk and select the option to create a new partition.

A dialog box will appear where you can set the partition size, file system, and label. Enter the desired values for the recovery partition, similar to what you did in the built-in method.

Follow the on-screen instructions to complete the partition creation process. The software will usually perform a series of checks and operations to create the partition.

Verify and Adjust (if needed)

After creating the partition, you can use the software to verify its properties and make any necessary adjustments. For example, you can check the partition size, file system, and make sure it is properly formatted.

Method 3: Using a Windows 10 Installation Media

Prepare a Windows 10 Installation Media

You can create a Windows 10 installation media using a USB drive or a DVD. You can download the Windows 10 ISO file from the official Microsoft website and use the Media Creation Tool to create the installation media.

Boot from the Installation Media

Insert the USB drive or DVD into your computer and restart it. Press the appropriate key (usually Del, F2. F10. or F12) during the boot process to enter the BIOS or UEFI settings. Set the boot order to prioritize the installation media.

Start the Installation Process

When the Windows 10 installation screen appears, select your language, time and currency format, and keyboard or input method. Click “Next”.

Select “Repair your computer”

Instead of clicking “Install Now”, click on “Repair your computer” at the bottom left corner of the screen.

Access the Command Prompt

In the “Choose an option” screen, select “Troubleshoot”. Then select “Advanced options” and choose “Command Prompt”.

Create the Recovery Partition

In the Command Prompt, use the same DiskPart commands as in Method 1 to create and format the recovery partition. Follow the steps carefully to ensure the partition is created correctly.

Complete the Process

After creating the recovery partition, you can copy the necessary system recovery files to it from the installation media or a backup. Then you can exit the Command Prompt and continue with the system recovery or reinstallation process if needed.

Considerations and Precautions

Data Backup

Before creating a recovery partition, it’s crucial to back up all your important data. Creating a partition may involve disk operations that could potentially cause data loss. Use external hard drives, cloud storage, or other backup methods to ensure your data is safe.

Disk Compatibility

Make sure that your hard drive is compatible with the partition creation process. Some older hard drives or certain types of storage devices may have limitations or issues. Check the manufacturer’s website for any compatibility information.

System Stability

Creating a recovery partition should be done on a stable system. Avoid creating a partition while the system is in the middle of other important operations or when there are software conflicts.

Recovery Partition Size

The size of the recovery partition depends on the amount of data you need to store. If you plan to include a full system image backup, you will need a larger partition. However, if it’s just for basic system recovery files, a smaller size may be sufficient.

Bootloader Configuration

After creating the recovery partition, you may need to update the bootloader to ensure that the system can access the recovery options. This is especially important if you are using a dual-boot system or have made significant changes to the disk layout.
